RAJKHAM KADAKSHAM

April 01, 2022

TYPE OF FOUNDATION AND STRUCTURE

RCC Framed Structure with RCC Columns @ regular intervals with isolated footings. All the columns will be interlinked by Plinth beam.

ROOF HEIGHT

10’0” for Ground floor, First floor, Second floor & Third floor including slab thickness, for 8’6” head room height including slab thickness normally roof thickness will be 4.5” to 5”.

SUPER STRUCTURE

External walls will be non load bearing 8” Solid block / Brick Masonry with C.M 1:6 & Internal walls will be non load bearing 4” Solid block brick masonry Walls with C.M 1:4 with 2nos of steel strips at every 3’0” interval (where necessary)

ROOF TREATMENT

Terrace floor weathering course will be used pressed clay tile finish.

LOFT

RCC loft of 1.5” thick with necessary bearing on one side in bed room and kitchen, hall with be no loft & cupboard, wood work will be extra cost.

ELECTRICAL

Concealed three phase electricity supply with FRLS wiring with Anchor Roma Modular switches will be used.

Light point 1 sq mm
Power point 15 amps & 5 amps
A/c power 4 sq mm
Geyser 5 sq mm

Inverter wiring included 1 Fan, 1 Light, 1 Socket for Living, Bed rooms, kitchen & 1 Light, 1 Socket for toilet.

KITCHEN

RCC or Cuddapah Slab will be 12’0” length with Black Galaxy granite top at the cost of Rs. 120/sft will be laid.
24” x 18” SS Sink with or without drain board will be provided
Above platform 4’0” height tiles will be laid .

FITTINGS

All fittings are (Lock, hinges, tower bolt etc) SS hardware except main door. Main door will be brass (Lock, hinges, tower bolt) or Antique.

FLOORING

Entire flat will have 2’ x 2’ Vitrified tiles flooring of basic colors will be laid. Balcony and passage flooring anti skid tile

TOILET

Walls will be finished with colored glazed tiles up to ceiling height 10” x 13” (Kajaria / Johnson) approved design for all toilet wall, toilet floor will be finished 1’ x 1’ ceramic antiskid tiles (fittings shall be one wash basin, closet, shower with arm, 2 in 1 wall mixer other than this are extra)

PAINTING

Interiors 1 coat of water base primer finished with 1 coat putty, 2 coats of premium emulsion paint will be used.

Exteriors & Ceiling 1 Coat of White Cement finished with 2 Coats of Apex.

PARAPET

Parapet wall will be 3’6” height with 4.5” wall with both side plastering necessary rings with be provided in terrace.

HEAD ROOM

Head room will be 8’6” height 9” outer wall with 4” thick roof will be laid terrace door grill safety gate will be provided.

AMENITIES:

Automatic Lift (8 Passenger)
Granite/Black or (Any other colour available except Green) Marble steps with SS handrail
Automatic on- off switch for bore, sump motor
CCTV provisions for ground floor area (wiring + camera will be given)
Hand pump, taps (Car parking, terrace floor)
Inverter wiring for Each flat
Covered car park
Genset Power backup for common area Including Lift
